2025 MAY FEATURED PRODUCTS BATTERIES AND BATTERY TOOLS
2025 MAY FEATURED PRODUCTS 2 HIGH-PERFORMANCE AGM MAINTENANCE-FREE BATTERIES • Premium-quality, maintenance-free battery at a great low price • Special absorbed-glass mat battery eliminates water loss, permitting the battery to be permanently sealed once it is filled with acid • Acid pack included, except where noted as Factory-Activated • Battery seals to prevent water loss • Holds charge three times longer than conventional batteries NOTE: Factory-Activated batteries should be charged once a month when not in service. NOTE: See the 2025 Parts Canada Street Catalogue or Tire and Service catalogue for battery application chart. YUASA REFERENCE # PART # YTX14AH-BS 2113-0030 YTX20H-BS 2113-0021 YTX20HL-BS 2113-0022 AGM MAINTENANCE-FREE BATTERIES • Premium-quality, maintenance-free battery at a great low price • Special absorbed-glass mat battery eliminates water loss, permitting the battery to be permanently sealed once it is filled with acid • Holds charge three times longer than conventional batteries • Truly the world’s finest “install it and forget it” motorcycle battery • Battery seals to prevent water loss • Acid pack included NOTE: See the 2025 Parts Canada Street Catalogue or Tire and Service catalogue for battery application chart. YUASA REF. # PART # YTX12-BS 165495 YTX14-BS 165496 YTX20L-BS 165466 YUASA REFERENCE # PART # CAPACITY AH (10-HR) REGULAR CHARGE CURRENT (AMP) COLD CRANKING AMPS @0 °F LENGTH WIDTH HEIGHT APPROX. WEIGHT W/ ACID (LBS.) TERMINAL CONFIGURATION YTX20H-BS YTX20H-BS 18 1.8 310 6 7/ 8” 3 7/ 16” 6 1/ 8” 15.1 + - YTX14AH-BS (includes 10 mm height spacer for use in replacing YB14A-A1 and YB14A-A2) YTX14AH-BS 12 1.2 210 5 5/ 16” 3 1/ 2” 6 9/ 16” 11.1 + - HIGH-PERFORMANCE AGM MAINTENANCE-FREE BATTERIES • This new generation of maintenance-free batteries delivers higher cranking amps for vehicles that require extra starting power • Additional cranking amps make these one of the most powerful batteries on the market • Acid pack included, except where noted as Factory-Activated NOTE: Factory-Activated batteries should be charged once a month when not in service. NOTE: See the 2025 Parts Canada Street Catalogue or Tire and Service catalogue for battery application chart.
2025 MAY FEATURED PRODUCTS 3 YUASA REFERENCE # PART # CAPACITY AH (10-HR) COLD CRANKING AMPS @0 °F LENGTH WIDTH HEIGHT APPROX. WEIGHT W/ ACID (LBS.) TERMINAL CONFIGURATION YTX14-BS YTX14-BS 12 200 6” 3 7/ 16” 5 3/ 4” 10.1 + - YTX20L-BS YTX20L-BS 18 270 3 7/ 16” 6 1/ 8” 13.9 - + YTX12-BS YTX12-BS 10 180 6” 3 7/ 16” 5 1/ 8” 9.2 + - YTX9-BS YTX9-BS 8 135 6” 3 7/ 16” 4 3/ 16” 6.6 + - AGM MAINTENANCE-FREE BATTERIES • Special absorbed glass mat battery eliminates water loss, permitting the battery to be permanently sealed once it is filled with acid • Truly the world’s finest “install it and forget it” motorcycle battery • Acid Pack included, except where noted as Factory-Activated NOTE: See the 2025 Parts Canada Street Catalogue or Tire and Service catalogue for battery application chart. YUASA REF. # PART # COLD CRANKING AMPS LENGTH WIDTH HEIGHT TERMINAL CONFIGURATION GYZ16HL 2113-0325 240 6” 3 7/ 16” 5 3/ 4” - + GYZ20H 2113-0323 320 6 7/ 8” 3 7/ 16” 6 1/ 8” + - GYZ20HL 2113-0324 320 6 7/ 8” 3 7/ 16” 6 1/ 8” - + GYZ32HL 2113-0322 500 6 9/ 16” 5” 6 7/ 8” - + DRAG SPECIALTIES PREMIUM PERFORMANCE BATTERIES • AGM (Absorbed Glass Mat) separators with superior grid and component designs allow Drag Specialties to offer one of the most powerful batteries in the industry • Improved charge recover capability from a deeply discharged condition • Longer shelf life • Improved life cycle performance • Extreme vibration resistance • Factory-Activated, spill-proof design • Upgrade for customized motorcycles requiring the best performance • PART #s 2113-0322, 2113-0323 and 2113-0324 feature new heavy-duty flush-mount terminals that eliminate the need for spacers ensuring a secure, vibration-resistant and direct-path connection • PART #2113-0325 with recessed box terminal includes square brass spacers for superior performance • PART #2113-0322 features a low-profile handhold for easy installation • Made in the U.S.A. 2113-0322 2113-0324 2113-0323 2113-0325
2025 MAY FEATURED PRODUCTS 4 DRAG SPECIALTIES HIGH PERFORMANCE BATTERIES • Specifically designed for high-performance engines that need extra cranking power • Superior engineering features include an AGM (Absorbed Glass Mat) radial grid design for maximum cranking amps • High vibration resistance • Spill-proof, pre-filled, pre-charged, maintenance-free sealed design (unless noted) • Batteries include brass spacers, stainless steel nuts, bolts and star washers • Made in the U.S.A. NOTE: Factory-Activated batteries should be charged once a month when not in service. YUASA REF. # PART # COLD CRANKING AMPS LENGTH WIDTH HEIGHT TERMINAL CONFIGURATION YTX20HL-BS 2113-0012 310 6 7/ 8” 3 7/ 16” 6 1/ 8” - + YIX30L 2113-0010 385 6 9/ 16” 5” 6 1/ 8” - + 2113-0010 2113-0012 YUASA REF. # PART # COLD CRANKING AMPS LENGTH WIDTH HEIGHT TERMINAL CONFIGURATION YIX30L-BSFT 2113-0782 450 6 9/ 16” 5” 6 7/ 8” - + DRAG SPECIALTIES AGM MAINTENANCEFREE BATTERIES • Specifically designed for hard-starting, high-performance engines that need extra cranking power • Radial grid technology delivers higher cranking amps and superior performance • Special absorbed glass mat battery eliminates water loss, permitting the battery to be permanently sealed once it is filled with acid; Acid Pack included • Superior vibration-resistance and durability provides a long service life • Each battery includes a quick-connect harness specifically designed for Drag Specialties battery chargers • PART #2113-0782 features a convenient, one-piece foldable handle for easy installation • PART #s 2113-0769, 2113-0780, 2113-0781, 2113-0782 feature new flush-mount terminal adapters that eliminate the need for spacers ensuring a secure, vibration-resistant and direct-path connection 2113-0780 DESCRIPTION PART # Repl. adapter hardware kit 2113-0307 REPLACEMENT ADAPTER HARDWARE KIT • For Drag Specialties’ batteries PART #s 2113-0209, 2113-0210 and 2113-0211 • Kit includes two “L” shape brass adapter nuts, four 6 x 13 mm bolts, four flat washers and an extra two 6 x 13 mm bolts, plus two flat washers which are used to fix “L” shape brass adapter nuts on battery DESCRIPTION PART # Cut-your-own battery cushion 2113-0077 CUT-YOUR-OWN BATTERY CUSHION • High-quality, pure neoprene foam cushion is nonabsorbent and retains its shape even under constant pressure • Cut-your-own kit is ideal for custom battery boxes and custom oil tanks • It fights off vibration, as well as pressure from the lid and strap, keeping battery damage to a minimum • Universal design for use in many applications; color is black • Measures 8” L x 5” W x 1/ 8” thick • Sold as 5-pack; retail is each • Made in the U.S.A.
2025 MAY FEATURED PRODUCTS 5 DESCRIPTION PART # OptiMate™ 3 global 3807-0261 OPTIMATE™ 3 GLOBAL COMPLETE 12V BATTERY CARE • An all-in-one tool for 12V battery care at home or shop • Diagnoses, recovers, charges, tests and optimally maintains, automatically • Retains all the fully automatic, 100% safe, easy-to-use characteristics of the two million OptiMates™ produced since 1995, but is now microprocessor-controlled, lighter and more efficient than ever • Comes with global input (100V to 240V) and is 33% more powerful than its predecessor • For batteries forgotten over the winter, OptiMate 3 will recover them from deep discharge and optimally recharge them; it will check that the charge delivered is the best possible, then check how well the battery can retain the charge • Batteries’ status can be checked at a glance • OptiMate 3 will then maintain the battery at full charge safely for months at a time and extend its life by up to 400% DESCRIPTION PART # 20 pk. 3807-0352 Six 20 pks. 3807-0677 EYELET CONNECTORS • Quick-connector permanent battery leads • Weather-protected connection system and cable • Industry standard 2-pin SAE connector • Length 20”/50 cm; eyelet diameter 1/ 4” and M6 weather-protected 15A fuse • -40 °C/-40 °F very low temperature use • Cable remains flexible at below-freezing temperatures • Rubber sealing cap and shroud for OptiMate™ heavy-duty SAE connector 3807-0352 DESCRIPTION PART # 10-unit 12V battery charger 3807-0443 BATTERY MANAGEMENT SYSTEM • Charges and/or maintains up to ten 12V batteries simultaneously • Advanced microchip circuitry won’t activate the output until the clips are correctly connected to a battery • Keeps batteries fully charged for months, if necessary, with absolutely no danger of overheating or overcharging • It is recommended that fluid levels be checked periodically during long charging periods • The Battery Tender® at 2-amp will charge as fast as or faster than any 5-amp charger on the market
2025 MAY FEATURED PRODUCTS 6 DESCRIPTION PART # LCD battery meter 3807-0232 LCD BATTERY METER • LCD displays battery voltage when the button is pressed • Displays voltage range of 3-16V • Resolution of +/- 0.1V • Flashes red when voltage is low • Plugs directly into Deltran QDC battery harness DESCRIPTION PART # Jumper cables YUA00ACC07 JUMPER CABLES • Simple to use and easy to store • Heavy-duty, 8’ 8-gauge cables won’t stiffen or freeze • Tangle-resistant; encased rubber grips for safety • Come with convenient storage bag DESCRIPTION PART # Digital battery tester w/ printer 3807-0437 Repl. printer paper rolls (2 pk.) 3807-0438 DIGITAL BATTERY TESTER WITH PRINTER • Developed exclusively for 12V powersports batteries 2.3 ~ 32AH • Determines battery health and charge status in seconds • Single load, dynamic resistance technology minimizes battery drain during test • Tests both charged and discharged batteries accurately • Digital battery tester prints recommended actions • Prints results in seconds • Charging system check • Dimensions: 195 mm L x 114 mm W x 50 mm H • Includes a heavy-duty plastic case, two rolls of printer paper and four AA batteries • Replacement printer paper rolls available separately 3807-0437 3807-0438 DESCRIPTION PART # Motorcycle jumper cables DS-310490 MOTORCYCLE JUMPER CABLES • 6’ L, 12-gauge cable • Durable coating and rubber-encased grips for safer, more efficient jumps
2025 MAY FEATURED PRODUCTS 7 DESCRIPTION PART # OptiMate™ 5 3807-0467 OPTIMATE™ 5 POWER CHARGER • Rapidly charges and optimizes the performance of 12V batteries • Multi-step charge, optimize and maintenance program ideal for all 12V sealed-starter and deep cycle AGM, EFB and lead-acid batteries • Safe low-volt pulsing recovery for accidentally discharged flat batteries • Advanced maintenance program keeps batteries 100% read while supporting “always on” circuitry • Includes premium weatherproof permanent battery lead and handlebar hanging hook DESCRIPTION PART # In-line spark tester 3804-0033 IN-LINE SPARK TESTER • Supplies a quick, easy visual check of ignition system • Works on all ignition systems, including distributorless ignitions • Made in the U.S.A. DESCRIPTION PART # OptiMate™ Test 3807-0245 OPTIMATE™ TEST TS121 BATTERY AND CHARGING SYSTEM/ ALTERNATOR TESTER • Fast, accurate and professional on-vehicle testing of 12V batteries and charging systems • Checks battery voltage to provide an indication of battery health; checks battery starting power and checks charging system without disassembly by indicating low charging voltage • Connect directly to the battery or “live” 12V outlet • Battery clips are removable and replaceable • Includes two cable straps, adhesive hook-and-loop straps and screws for use if mounting the removable backplate into an enclosure DESCRIPTION PART # Ignition system tester MP08-122 IGNITION SYSTEM TESTER • Test the integrity and strength of your ignition system • Spark gap is adjustable from 0 to 10 mm • The larger the gap your ignition will jump, the stronger your system is • Will test the ignition on most motorcycles, watercraft, ATVs and snowmobiles
2025 MAY FEATURED PRODUCTS 8 DESCRIPTION PART # 01 permanent battery lead 3807-0259 01 PERMANENT BATTERY LEAD • Weatherproof cap • -40 °C/-40 °F very low temperature use; cable remains flexible at ‘below freezing’ temperatures • Molded ringlets • Will work with Moose Utility Division OptiMate™ 3 and OptiMate 6 battery chargers • Available individually or in a jar of 20 3807-0259 DESCRIPTION PART # 12V battery eyelet connector w/ integrated state of charge monitor for lead-acid batteries; 24” L 3807-0500 12V battery eyelet connector w/ integrated state of charge monitor for lithium LiFePO4 batteries; 24” L 3807-0501 OPTIMATE BATTERY STATUS/ CHARGE SYSTEM MONITORS • Permanent battery leads with integrated battery status/charge system monitors for 12V lead-acid batteries or lithium batteries • Monitor charge or confirm if the charging system is working correctly • Two automatic modes: battery charge level monitor and charging system test • SAE charge port with weatherproof sealing cap 3807-0500 3807-0501 DESCRIPTION PART # Digital Circuit Tester 3807-0660 DIGITAL CIRCUIT TESTER • Red backlit display indicates positive polarity and green backlit display indicates negative polarity • Stainless steel probe with 12” coiled cord and alligator clamp for secure connections • Operating range 2.6 to 32VDC to work on most vehicle electrical systems • Heavy-duty circuit tester with digital display to accurately show DC voltage DESCRIPTION PART # 22 oz. 2113-0969 32 oz. 2113-0970 ACID BOTTLES • Specially designed containers that hold high-quality electrolyte acid for activating and maintaining lead-acid batteries 2113-0970
